Our Products

---

 19"standard and Suitable for being installed in different kinds of optical distribution frames or cabinets Two core rotary distribution module is vertically arranged and can be rotated out of the box for easy

operation, management, and maintenance

Fiber guiding hoops on the front and rear sides protect fibers from mechanical damage and are arranged to ensure bending radius protection. Fiber can be inserted into the guiding hoop directly, with no need for an interlude. Adapter panels are selectabl

• Fiber splice module accommodates all methods of fiber optic splicing.

• Large drawers accommodate bend radius for all cables.

• Fluid movement of drawers prevents vibration.

• Available in 19” or 23” modules.

• Fits for FC, SC, ST, and LC adapters

Small size with electrostatic spraying surface

Cables fixed by gland and stainless hoop, stable and reliable Could be used as distribution box or splicing unit

According to the customer's requirement, FC/SC/ST type adapter panels are selectable Support several kinds of installation way

The water-resistant door with a 3-point locking mechanism protects the cabinet against dust and moisture intrusion and unauthorized entry.

12 cores integrated distribution and splicing module suitable for FC and SC adapter installation

Optimal arrangement for optical cables and fibers with fiber storage unit Reliable cable fixing and grounding unit.

The two-layer body construction filled with heat isolative material inside has good heat insulation performance, and can effectively prevent conden

• Optical joint enclosures can be used in aerial, wall-mounted, underground, direct buried, and duct-mounted applications.

• The housing of the closure is made of enhanced engineering plastic PC with excellent aging, intensity, and fire-resistant performance. It is used for optical cable/fiber connection and protection in straight-through or branching applications.

• With high-performance sealant, fixing bolts, and cable fixing hoop, the closure ensures waterproof, long-term reliability, and u

• Suitable for telecommunication networks, CATV and multimedia systems, data processing networks

• Ceramic ferrule with high durability and reliability

• Stable withdrawal force (200-600fg)

• UPC/APC type available with Low insertion loss• Optical joint enclosures can be used in aerial, wall-mounted, underground, direct buried, and duct-mounted applications.

• The housing of the closure is made of enhanced engineering plastic PC with excellent aging, intensity, and fire-resistant performance. It i

Generally accepted color code for APC and UPC connector:

a. Green for APC SMF connectors

b. Blue for UPC SMF connectors

c. Beige for UPC MMF connectors

Generally accepted color code for MMF and SMF connector:

a. Beige for multi-mode fiber

b. Blue for single-mode fiber

• A fused conical optical splitter is used for multiple optical power distribution.

• It features a small size, adjustable optical splitting ratio, high stability, low additional loss, and polarization-dependent loss.

• Planar Waveguide splitter is fabricated by using silica waveguide technology.

• It features small size, wide operating wavelength range（1260-1650nm, high reliability and good signal uniformity,

• Low Insertion Loss & Back Reflection

• Environmentally Stable, good repeatability and interchangeability

• 2,4,6,8,12 and 24 Channels Available

• Cable diameter:0.9mm, 2.0mm, 3.0mm

• Save Duct Space, Cost, and Installation time

• Easy Push/Pull Operation

• 19" standard installation, adjustable position in the forward and backward direction, applicable for various cabinet and rack installation

• Compact aluminum body with electrostatic spraying surface, light structure, and fine-looking appearance

• Protection of arc-shaped plastic part, preventing optical fiber from damage or strain.

• Kind’s adapter panels make it convenient and flexible in usage.

• Large tray body, customized output panel for pigtail is available.

  • Ladders are designed for light-duty, medium-duty, and heavy-duty cable loading requirements.

• Provide to cross long unsupported spans with fewer supports

Distribution and Drop Optical Cables for FTTH and FTTP Applications (Single mode fiber optic cable is most used)

1. The loose Tube family of fiber optic cables is designed for outdoor and indoor/outdoor use as the network backbone whether it is for aerial lashed or underground applications.

The Non-Armored Loose Tube family is an all-dielectric construction meaning it contains no metallic components, therefore no bonding or grounding is required. Armored Loose Tube Double Jacket/Single Armor fiber optic cables are designed to provide high fiber counts with the flexibility and versatility.

 Directly buried cables are buried under the ground without separate coverings, and therefore they might face extreme conditions, for example, changing temperatures and moisture.

The installation environment dictates the needed level of protection in these cables.

Arial Cables are designed to be lightweight but also strong enough to be installed between support towers. The cables must also withstand the strain of the natural elements, for example, wind and ice. Applications: Outdoor aerial installations along utility poles for cable Television, Telecom, or other outside plant campus backbone networks

Arial Cables are designed to be lightweight but also strong enough to be installed between support towers. The cables must also withstand the strain of the natural elements, for example, wind and ice. Applications: Outdoor aerial installations along utility poles for cable Television, Telecom, or other outside plant campus backbone networks

 • Refined outline with top degree quality

• Integrated welding structure, high intensity

• Cold rolled steel body with electrostatic spraying surface

• Three-point locks with high-degree revolve cabinet locks and code locks are selectable.

• Plastic parts on two sides of the front make cable management easily.

• Superficial protective

19" standard installation

The side panel could be pulled off for easy Equipment maintenance.

Could place fans, tray, power socket, etc

For outdoor applicationsWeatherproof and dustproof, meeting IP65. Well protected from accidental or malicious damages Complete cable routing design with fiber bend radius over 40mm. Modular design and easy installation, modules are exchangeable.

Optimal management for patch cords with fiber storage units. Suitable for ribbon and non-ribbon optical fibers

 Convert AC to DC.

There are two types:

a. Centre Tapped

b. Bridged

o Single Phase Rectifiers

a. DPR 2900 EnergE - Hot pluggable fan-cooled rectifier provides the 36.5W/in³ power density

b. DPR 3000 EnergE - hot-pluggable fan-cooled rectifier provides the 56.8W/in³ power density

o Three-Phase Rectifiers

a. DPR 6000-48 series - wide input voltage range and low input current distortion help lower the cost in the AC installation

 DC to DC converter, converting between the voltage levels of battery systems to the voltage requirement of equipment

 • SPD is a component of the electrical installation protection system.

• Most used as the most efficient type of overvoltage protection
